Product Description
1.key Details:
Place of Origin: Hebei, China (Mainland) ; Brand Name: Jaoyao or OEM ; Model Number: Telecom Tower
Surface treatment: Hot Dip Galvanizied or painted.
2.Packaging & Delivery:
Packaging Details: Telecom tower will be bundled by Galvanized strapping as per client's requirements.
Deliver:Shipped in 20 days after payment from Tianjin port
Tower members: One steel tower is separated into several bundles.
Bolts: Packing material is robust nylon bag or steel drum.
3. Technical Data
| Design |
| 1. Design Code | TIA/EIA-222-G/F |
| Structure Steel |
| 2. Grade | Mild Steel | High Tensile Steel |
| GB/T 700:Q235B, Q235C,Q235D | GB/T1591:Q345B, Q345C,Q3455D |
| ASTM A36 | ASTM A572 Gr50 |
| EN10025: S235JR, S235J0,S235J2 | EN10025: S355JR, S355J0,S355J2 |
| 3. Design Wind Speed | Up to 250 km/h |
| 4. Allowable deflection | 0.5 ~1.0 degree @ operational speed |
| 5. Tension strength (Mpa) | 360~510 | 470~630 |
| 6. Yield strength (t≤16mm) (Mpa) | 355 | 235 |
| 7. Elongation (%) | 20 | 24 |
| 8. Impact strength KV (J) | 27(20°C)---Q235B(S235JR) | 27(20°C)---Q345B(S355JR) |
| 27(0°C)---Q235C(S235J0) | 27(0°C)---Q345C(S355J0) |
| 27(-20°C)---Q235D(S235J2) | 27(-20°C)---Q345D(S355J2) |
| Bolts & Nuts |
| 9. Grade | Grade 4.8, 6.8, 8.8 |
| 10. Standards for mechanical properties |
| 10.1 Bolts | ISO 898-1 |
| 10.2 Nuts | ISO 898-2 |
| 10.3 Washers | ISO 6507-1 |
| 11. Standards for Dimensions |
| 11.1 Bolts | DIN7990, DIN931, DIN933 |
| 11.2 Nuts | ISO4032, ISO4034 |
| 11.3 Washers | DIN7989, DIN127B, ISO7091 |
| Welding |
| 12. Method | CO2 Shielded Arc Welding & Submerged Arc Welding(SAW) |
| 13. Standard | AWS D1.1 |
| Marking |
| 14. Method of marking of the members | Hydraulic Press Stamping |
| Galvanizing |
| 15. Galvanization standard of steel sections | ISO 1461 or ASTM A123 |
| 16. Galvanization standard of bolts and nuts | ISO 1461 or ASTM A153 |
| Test |
| 17. Factory test | Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending,
Preece test,Hammer test |
| Capacity |
| 18. Maximum Production Capacity | 50,000 TON per annum |
Whta is the Antenna Bracket of monopole tower?
What is the Ladder of Monopole Tower?
What is the cable hole and antenna bracket of monopole tower?
How to fix the feeder in the monopole tower?
How to connect monopole tower with foundation?
How to overlap and install monopole tower?
Please Click Here For More Information!!!
Production Flow
Customer Visits
Certifications
Please Click Here For More Information!!!
Customized product types & advantage
Self Supporting Tower
Self supporting tower usually is 3leg of 4leg tower, and its material is steel pipe or angle steel. As for the connection, tubular tower is connected by flange, and angle steel tower is connected by nuts and bolts.
Features:
1.Small coefficient of wind load, strong wind resistance.
2.Save land resource, convenient location.
Convenient transportation and installation.
Pipe Steel Tower
The tube tower refers to a self-supporting high-rise steel structure with a tower column made of steel pipes and a tower body section in a triangular shape. Its main characteristics are that the three tube tower column is made of steel pipes and the tower body section is in a triangular shape, which is a high-rise steel structure different from angle steel.
Monopole Tower
Single tube tower also called monopole tower, is a commonly used type, with beautiful appearance, covering an small area of 9 to 18 square meter, cost - effective , and is adopted by majority of the construction. Tower body adopt more reasonable section, which is connected through high strength bolt. It has the characteristics of easy installation and can adapt to a variety of complicated field site.
Guyed Tower
Guyed tower has a novel appearance,and its biggest characteristic is strengthened by using steel guy wire. Guyed tower is a common type of communication tower which is economical and practical. It is lighter and cheaper than the others. It is very suitable for the geographical wide areas.
Guard Tower
The watchtower is a multifunctional building mainly used for observing the surrounding environment and playing an important role in multiple fields. Its design emphasizes harmony and unity with the natural environment, and the architectural style is usually coordinated with the surrounding environment. Observation towers are usually composed of tower bodies, platforms, towers, and ladders, with compact and durable structures.
Camouflaged Tree Tower
Camouflaged Tree Tower is also a kind of cartificial trees of Bionic tree tower, on base like a real one, plus the meticulous design, when placed among the real trees in sightseeing area, park and square, it will be a part of the nature.
Features:
1. Exquisite structure and gorgeous appearance.
2. Strong structural stability and long working life.
3. Small area covering and great economic effect.
Our Services
Company Information
JIAYAO CO.,LTD. is a professional telecom tower manufacturer and approved by ISO 9001.we can supply OEM/ODM Manufacturing. JIAYAO has been qualified by SGS classification as well as we have our own import and export license,our products such as angle steel tower, tube steel tower, monopole tower, pine tree tower, guyed tower and guard tower have been exported to USA, Europe and other 55 different counties. It's only two hours' drive from Shijiazhuang airport to JIAYAO.
If you need it, we will welcome you 24 hours a day!
